SH170-90
SH170-90
Road clearance technology: power packs, cranes and flails for profession use.
We build road clearance machines for the people who make our roads safer. By designing all the parts from the power pack to the cutting head, we deliver solutions to suit your construction machinery and the jobs you have to do. We also guarantee high quality in every component. It pays to think wider.
| Diesel engine cylinders | 4 |
| Max output (kW / hp / rpm) | 129.4 /176 / 2200 |
| Max torque (Nm/rpm) | 750 / 1400 |
| Hydraulic system max. pressure | 350 bar |
| Weight | 1700 kg |
| Diesel tank | 200 l / 15 l |
| Diesel engine cylinders | 4 |
| Max output (kW / hp / rpm) | 55,4 / 75,3 / 2400 |
| Max torque (Nm/rpm) | 424 / 1200 |
| Hydraulic system max. pressure | 250 bar |
| Weight | 1400 kg |
| Diesel tank | 154 l |
| Diesel engine cylinders | 4 |
| Max output (kW / hp / rpm) | 129,4 / 176 / 2200 |
| Max torque (Nm/rpm) | 750 / 1400 |
| Hydraulic system max. pressure | 260 bar |
| Weight | 1700 kg |
| Diesel tank | 200 l |
| Reach, slewing motor centre - outermost link | 11075mm (SH210) |
| Boom extension | 3700 mm |
| Weight including oil | 2500 kg |
| Max. reach | 11.075 mm (SH210) |
| Slew system | Twin rack slewing motor |
| Slew angle | 200° |
| Boom extension (telescope) | 3.700 mm |
| Reccomended flow | 130-200 l/min |
| Working pressure | 235 bar |
| Weight including oil | 2.500 kg |
| Reach, slewing motor centre - outermost link | 8450 mm (SH120) |
| Boom extension | 1700 mm |
| Weight including oil | 1430 kg |
| Max. reach | 8.450 mm (SH210) |
| Slew system | Twin rack slewing motor |
| Slew angle | 370° |
| Boom extension (telescope) | 1.250 mm |
| Reccomended flow | 60-120 l/min |
| Working pressure | 235 bar |
| Weight including oil | 1.430 kg |
| Reach, slewing motor centre - outermost link | 7390 (SH170) |
| Boom extension | 1700 mm |
| Weight including oil | 1340 kg |
| Max. reach | 7.390 (SH170) |
| Slew system | Twin gear rack slew motor |
| Slew angle | 370° |
| Boom extension (telescope) | 1.700 mm |
| Reccomended flow | 60-110 l/min |
| Working pressure | 235 bar |
| Weight including oil | 1.340 kg |
| Reach, slewing motor centre - outermost link | 6200 (SH150) |
| Boom extension | 1430 mm |
| Weight including oil | 650 kg |
| Max. reach | 6.200 mm (SH150) |
| Slew system | Twin rack slewing motor |
| Slew angle | 380° |
| Boom extension (telescope) | 1.430 mm |
| Reccomended flow | 60-80 l/min |
| Working pressure | 215 bar |
| Weight excluding oil | 650 kg |
| Working width | 1.250 mm |
| Weight | 525 kg |
| Hydraulic motor | 60 cc |
| Working width | 1.250 mm |
| Weight | 525 kg |
| Hydraulic motor | 60 cc |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 100 l/min |
| Hydraulic oil flow Ideal | 120 l/min |
| Hydraulic oil flow Max. | 140 l/min |
| Working width | 1.500 mm |
| Weight | 585 kg |
| Hydraulic motor | 80 cc |
| Working width | 1.500 mm |
| Weight | 580 kg |
| Hydraulic motor | 80 cc |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 100 l/min |
| Hydraulic oil flow Ideal | 130 l/min |
| Hydraulic oil flow Max. | 150 l/min |
| Working width | 1.700 mm |
| Weight | 665 kg |
| Hydraulic motor | 90 cc |
| Working width | 1.700 mm |
| Weight | 665 kg |
| Hydraulic motor | 90 cc |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 100 l/min |
| Hydraulic oil flow Ideal | 130 l/min |
| Hydraulic oil flow Max. | 160 l/min |
| Working width | 1.900 mm |
| Weight | 750 kg |
| Hydraulic motor | 110 cc |
| Working width | 1.900 mm |
| Weight | 750 kg |
| Hydraulic motor | 110 cc |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 100 l/min |
| Hydraulic oil flow Ideal | 130 l/min |
| Hydraulic oil flow Max. | 160 l/min |
| Working width | 2.100 mm |
| Weight | 780 kg |
| Hydraulic motor | 125 cc |
| Working width | 2.100 mm |
| Weight | 780 kg |
| Hydraulic motor | 125 cc |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 120 l/min |
| Hydraulic oil flow Ideal | 145 l/min |
| Hydraulic oil flow Max. | 170 l/min |
| Working width | 1.500 mm |
| Weight | 530 kg |
| Hydraulic motor | 60 cc |
| Working width | 1.500 mm |
| Weight | 530 kg |
| Hydraulic motor | 60 cc |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 80 l/min |
| Hydraulic oil flow Ideal | 95 l/min |
| Hydraulic oil flow Max. | 110 l/min |
| Working width | 1.500 mm |
| Weight | 540 kg |
| Hydraulic motor | 80 cc |
| Working width | 1.500 mm |
| Weight | 540 kg |
| Hydraulic motor | 80 cc |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 100 l/min |
| Hydraulic oil flow Ideal | 130 l/min |
| Hydraulic oil flow Max. | 150 l/min |
| Working width | 1.598 mm |
| Weight | 555 kg |
| Hydraulic motor | F12-40 |
| Working width | 1.598 mm |
| Weight | 555 kg |
| Hydraulic motor | F12-40 |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 100 l/min |
| Hydraulic oil flow Ideal | 130 l/min |
| Hydraulic oil flow Max. | 150 l/min |
| Power requirement | 45 kW |
| Working width | 1.310 mm |
| Weight | 500 kg |
| Hydraulic motor | F12-40 |
| Working width | 1.310 mm |
| Weight | 500 kg |
| Hydraulic motor | F12-40 |
| Hydraulic oil pressure | Min 210 bar / max 380 bar |
| Hydraulic oil flow Min. | 100 l/min |
| Hydraulic oil flow Ideal | 130 l/min |
| Hydraulic oil flow Max. | 150 l/min |
| Power requirement | 45 kW |
