Technical data
| Diesel engine | Manufacturer | CAT |
| Model | C3,6 | |
| Fulfil exhaust emission levelregulation | STEG V | |
| Cylinders | 4 | |
| Displacement (litre) | 3,62 | |
| Injection system | Electronic | |
| Fuel intake system | Turbo with charge air cooler | |
| Max power (kW / hp /rpm) | 55,4 / 75,3 / 2400 | |
| Max torque (Nm / rpm) | 424 / 1200 | |
| Hydraulic system | Pump mower | Rexroth A20VO60 |
| Max pressure (bar) | 285 | |
| Filter | 10 μm | |
| Crane pump | Rexroth A20VO60 | |
| Max pressure (bar) | 250 | |
| Main valve | Parker P70 | |
| Electric system | Voltage | 24V DC |
| Battery capacity | 2x60Ah | |
| Alternator | 100A | |
| Control system | Control units | Parker IQAN |
| Joysticks | 5-prop | |
| Alarm functions | Oil pressure, engine temperature, charging, enginefunction, exhaust cleaning hydraulic oil level, hydraulic oil temperature, fuel level |
|
| Start – stop of mower | Proportional with ramp function | |
| Throttle control | Electric | |
| Weight and volume | Weight (kg) | 1400 |
| Diesel tank (litres) | 154 | |
| Hydraulic oil tank (litres) | 104 | |
| Hydraulic system (litres) | 125 |
